FAYMONVILLE
Küçük ilan
Hedensted
2.656 km
Düşük yükleyici
FaymonvilleMachine trailer / Maschinenauflieger
Ara
Durum: iyi (kullanılmış), makine/araç numarası: YAFTL4000J0022411, dingil konfigürasyonu: 3 aks, dingil mesafesi: 8.020 mm, renk: kırmızı, Üretim yılı: 2019, = Diğer seçenekler ve donanımlar =
- Arka hava süspansiyonu
- Ön hava süspansiyonu
- Kampanalı fren sistemi
= Diğer bilgiler =
Ağırlıklar
Boş ağırlık: 15.200 kg
Yük kapasitesi: 32.800 kg
toplam izin verilen ağırlık: 48.000 kg
Durum
Teknik durumu: iyi
Görsel durumu: iyi
Diğer bilgiler
Ön lastik durumu: 20
Arka lastik durumu: 20
Ön lastikler: 245-70 R 17.5
Arka lastikler: 245-70 R 17.5
Dsdewx Ea Hopfx Afveuu
Diğer bilgiler
Daha fazla bilgi almak için Lastas Satış ile iletişime geçin.
Küçük ilan
Deventer
2.675 km
Düşük yükleyici
FaymonvilleF-S43-1ACA
Ara
Durum: iyi (kullanılmış), dingil konfigürasyonu: 3 dingil, izin verilen dingil yükü (dingil 1): 10.700 kg, izin verilen dingil yükü (dingil 2): 10.700 kg, izin verilen aks yükü (aks 3): 10.700 kg, ilk tescil: 03/2013, süspansiyon: hava, lastik boyutu: 235/75R17.5, renk: kırmızı, Üretim yılı: 2013, = Additional Options and Equipment =
- Air suspension
= Remarks =
Duodpfx Ajyw Sxtjfvju
Faymonville Euro low-loader with removable gooseneck for sale
Specifications:
4 recessed wheel wells, each 2 meters
Width: 2.55 m
Extensions: 0.25 m
Low bed: 8 meters
Deck over axles: 4.30 m
Gooseneck upper length: 3.10 m
Loading height in drive position: 0.50 m
German registration
Tyres: 80 percent tread
SAF axles
3 steerable axles
Robust and well-maintained low-loader, immediately ready for heavy-duty transport.
= Further Information =
Axle configuration
Tyre size: 235/75R17.5
Axle manufacturer: SAF
Suspension: Air suspension
Rear axle 1: Dual tyres; Max. axle load: 10,700 kg; Steerable; Tyre tread left inside: 70%; Tyre tread left outside: 70%; Tyre tread right inside: 70%; Tyre tread right outside: 70%
Rear axle 2: Dual tyres; Max. axle load: 10,700 kg; Steerable; Tyre tread left inside: 70%; Tyre tread left outside: 70%; Tyre tread right inside: 70%; Tyre tread right outside: 70%
Rear axle 3: Dual tyres; Max. axle load: 10,700 kg; Steerable; Tyre tread left inside: 70%; Tyre tread left outside: 70%; Tyre tread right inside: 70%; Tyre tread right outside: 70%
Weights
Unladen weight: 14,700 kg
Payload: 17,400 kg
Gross vehicle weight: 32,100 kg
Condition
Technical condition: good
Visual condition: good
Product Safety
Manufacturer: Faymonville BE
Further Information
Please contact Gerrit Haverhoek for more information.
Küçük ilan
Dortmund
2.568 km
Alçak şasi dorse
Faymonville4-1+3-Achs-Tele-Semi-Radmulden-Rampen-zg
Ara
Durum: ikinci el, boş ağırlık: 15.550 kg, azami yük ağırlığı: 47.450 kg, toplam ağırlık: 63.000 kg, dingil konfigürasyonu: 3 aks, ilk tescil: 11/2024, yükleme alanı uzunluğu: 8.800 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 R 17,5, Üretim yılı: 2024, Donanım: ABS, For every used semitrailer, you will receive a current and comprehensive inspection and functional report.
Gooseneck:
- Gooseneck in SNT design for optimized loading area length, approx. 3,700 mm long
- Gooseneck rear with chamfer, approx. 1,000 mm x 10°
Loading area:
- Extendable loading platform, approx. 8,800 mm long, with rear chamfer approx. 500 mm x 10°
- A recess in the loading platform, including into the chamfer, for accommodating the excavator bucket arm
- Pneumatic locking system with conical locking pins and reinforced locking positions
- Hardwood flooring on the loading platform chamfer
Ramps:
- 1 pair of two-part steel ramps, approx. 4,350 mm long and approx. 900 mm wide
- Ramps laminated with hardwood
- Hydraulically foldable ramp tips
- Ramps can be hydraulically moved individually approx. 235 mm outward and approx. 215 mm inward
- Square serrated crossbars 20 x 30 mm, every approx. 200 mm on the outer frame of the ramp
Axles and suspension:
- BPW axles and suspension, first axle self-steering, all other axles hydromechanically forced steering
- Technical axle load: 12,000 kg
- Air suspension
- Tyres 235/75 R 17.5
- TPMS tyre monitoring system
- TPMS tyre sensors
Accessories included:
- Removable front wall, steel, approx. 400 mm high
- 3kW electro-hydraulic power unit for hydraulic operations
- 1 spare wheel
- External beams of the gooseneck with mounting holes for bolt-on lashing rings
- First hole approx. 200 mm from the front, then approx. every 400 mm
- 2 pairs of screw-in lashing rings included
- 1 pair of horizontal lashing rings at the rear of the gooseneck
- On the gooseneck: 1 pair of plug-in ALU sidewalls, approx. 400 mm high, anodized
- On the gooseneck: 1 plug-in ALU rear wall, approx. 400 mm high, anodized
- 2" king pin
- Round NATO socket at the front connection bar
- 4 wheel chocks
- Mechanical landing legs with 2-speed gearbox and crank
- 1 intermediate table, approx. 300 mm wide
- 1 pair of lashing rings on the front cross member
- 8 pairs of recessed, foldable lashing rings in the outer frame of the loading area
- Expandable (galvanized) extensions up to approx. 230 mm per side
- Wheel recesses with square serrated strips, 15 x 15 mm, continuously open ahead of the axles up to the gooseneck cross member, approx. 700 x 410 mm
- ALU covers for wheel recesses
- ALU elements lockable on the extension tubes of the width extensions
- Expandable U-profiles for ALU covers
- Wheel recesses with square serrated strips, 15 x 15 mm between the 1st and 2nd axle, approx. 1,480 x 700 x 410 mm
- ALU elements lockable on the extension tubes of the width extensions
- 1 pair of mechanical rear supports
- Rear steering operable from front and rear via cable remote control, with axle tracking control
- 1st axle with automatic lift axle function and starting aid in accordance with EU Directive 2021/535
- Under the gooseneck and at the rear crossbar left and right, each with a 7-pin socket with holder for warning boards
- Square serrated strips 20 x 30 mm, every approx. 200 mm on the outer frame of the loading platform chamfer
- Central lubrication system with 1 pump, brand BEKAMAX
Dedpfjypb Akex Afvouu
- Radio remote control for rear steering, in addition to cable remote
- Wabco Smart Board system
- 4 extendable warning boards, approx. 423 x 423 mm, extendable by approx. 400 mm
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
Faymonville4-1+3-Achs-Tele-Semi-Radmulden-Rampen zg
Ara
Durum: yeni, boş ağırlık: 15.550 kg, azami yük ağırlığı: 47.450 kg, toplam ağırlık: 63.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 8.800 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 R 17,5, renk: gri, Donanım: ABS, Gooseneck:
- Gooseneck in SNT design for optimizing loading platform length, approx. 3,700 mm long
- Rear gooseneck with bevel, approx. 1,000 mm x 10°
Loading Platform:
- Extendable loading platform, approx. 8,800 mm long, with rear bevel approx. 500 mm x 10°
- A recess in the loading platform as well as into the bevel for accommodating the excavator bucket arm
- Pneumatic locking with conical locking bolts and reinforced locking positions
- Hardwood flooring on the bevel of the loading platform
Ramps:
- 1 pair of two-piece steel ramps, approx. 4,350 mm long and approx. 900 mm wide
- Ramps with hardwood covering
- Hydraulically foldable ramp tips
- Ramps individually hydraulically adjustable approx. 235 mm outward and approx. 215 mm inward
- Square climbing strips 20 x 30 mm, at approx. 200 mm intervals on the outer frame of the ramp
Axles and Suspension:
- BPW axles and suspension, first axle steerable, all other axles hydro-mechanically forced steered
- Technical axle load: 12,000 kg
- 1st axle with electromagnetic reverse lock, activated automatically in reverse gear and manually
- Air suspension with lift and lower valve
- Tires: 235/75 R 17.5 twin tires
- TPMS tire monitoring system compliant with ECE R141
- TPMS tire sensors installed in all wheels, including spare wheels
Dusdpfx Afok Aht Ujvju
Accessories included:
- Detachable front wall, steel, approx. 400 mm high
- 3kW electro-hydraulic power unit for operating hydraulic functions, except hydraulic cable winch
- Parking bracket for warning signs on gooseneck when not in use
- 1 spare wheel
- On the gooseneck: 1 pair of detachable ALU side boards, approx. 400 mm high, anodized
- On the gooseneck: one detachable ALU rear board, approx. 400 mm high, anodized
- Over the gooseneck: approx. 40 mm thick hardwood covering, checker plate covering above king pin
- 2'' king pin
- Guide plate on the gooseneck for the fifth wheel plate, approx. 500 mm wide
- 4 wheel chocks
- Mechanical landing gear with two-speed gearbox and crank
- JOST Modul B – static test load = 50,000 kg
- 1 intermediate table, approx. 300 mm wide
- Telescopic width extensions (galvanized) approx. 230 mm per side
- Wheel recesses with square climbing strips
- ALU covers for the wheel recesses
- 1 pair of mechanical rear supports
- Remote steering from front and rear via cable remote control, with single track axle monitoring
- 1st axle with automatic lifting axle function
- Central lubrication system with 1 pump, BEKAMAX brand
- Wireless remote control for remote steering, in addition to cable remote, with 2 indicator lights on receiver for single track monitoring
- Wabco Smart Board System
- 4 warning signs, approx. 423 x 423 mm, extendable by approx. 400 mm, incl. 2 position lights and brackets for beacon
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
FaymonvilleMAX Trailer 5-Achs-Tele-Semi mit hydr. Rampen
Ara
Durum: yeni, boş ağırlık: 15.420 kg, azami yük ağırlığı: 61.080 kg, toplam ağırlık: 76.500 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 8.600 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 900 mm, lastik boyutu: 235/75/r17,5, renk: gri, Donanım: ABS, Gooseneck:
Gooseneck with rear bevel approx. 750 mm x 10°
3 pairs of lashing rings
Duedpfx Afel Sl Izsvju
30 mm thick hardwood flooring
Load area:
Extendable load area with rear bevel approx. 500 mm x 8°
8 pairs of outward folding lashing rings
1 pair of flat-fitted lashing rings at the front of the load area
Recesses in the outer frame of the loading area for attaching tie-down straps
Approx. 48 mm thick hardwood flooring, checker plate covering above the axles
Two-piece steel ramps:
One pair of galvanized two-piece steel ramps, approx. 2,750 + 1,400 x 800 mm, with approx. 48 mm thick hardwood covering. Ramp sections hydraulically lift and fold, hydraulically height-adjustable, and hydraulically shiftable. Maximum load per pair: 50,000 kg.
Landing legs:
• JOST landing legs (mechanical) with 2-speed gearbox for 24 t lifting capacity (50 t test load)
Axles and tires:
BPW axles and suspension, 4th and 5th axles steering
Technical axle load: 12,000 kg
4th and 5th axles with electro-magnetic reverse lockout, activated via reverse gear and manually
Tires 235/75 R 17.5 3PMSF
Braking system:
Braking system according to EU regulations with EBS-E (4S3M)
Sockets and lighting:
Electrical system in accordance with EU regulations, lighting 24 volts
ASPÖCK-NORDIK (ASS3)
ASPÖCK-UNIBOX at the front connector rail with sockets 24N, 24S & 15 pin
Connection compliant with ISO:
24N ISO-1185
24S ISO-3731
15 pin ISO-12098
Paintwork:
First-class and durable corrosion protection of the standard shot-blasted welded frame, ensured by a 2-component (2K) zinc dust primer
High-quality 2-component (2K) topcoat, single color MB 7350 Novagrau
Rear part metalized and painted in RAL 9010 (pure white)
No metallic paint possible
Steel construction:
Steel construction made of high-strength fine-grain steels
Steel grades:
S355J2+N/S355MC (yield strength 355 MPa)
S690QL/S700MC (yield strength 690 MPa)
Accessories:
One spare wheel with holder in front of bulkhead
2" kingpin
One galvanized steel front wall, approx. 400 mm high
Yellow-red air couplings mounted on the galvanized connector rail at the front
2 wheel chocks with holder on the front wall
Bracket at rear of gooseneck for ALU drive-on ramps
One holder for a rotating beacon at the rear of the trailer
Galvanized supports beneath the rear bevel of the loading area
White reflector tape according to EU regulations on the sides, extension, and rear in red
Electro-hydraulic unit at rear under the loading area
Mounts for warning signs with socket at the gooseneck and rear plate left and right
Ramp control valves fitted to right-hand side of the trailer
One mud flap at the rear of the trailer
Manual and documentation on USB stick
3.5" kingpin supplied loose
Plug-in ALU sideboards and rear wall on the gooseneck approx. 2,440 x 400 mm (LxH)
Rear galvanized drop-in stakes are removable (structure length approx. 2,560 mm)
3 pairs of WADER container pockets in the loading area for a 20' (30') or 40' container
6 pairs of stake pockets for plug-in stakes 100 x 50 mm in the outer frame of the loading area
Galvanized extensions, extendable by approx. 230 mm per side
Lifting axle on the front axle with control via TEBS E, depending on the current axle load and current loading condition
Square cleats 20 x 20 mm every 200 mm on the outer frame of the loading area's bevel
On the checker plates, above the kingpin and the loa...
Küçük ilan
Dortmund
2.568 km
Açık kasa ve brandalı treyler
FaymonvilleMT 3-Achs-Jumbo-Semi-Rampen-Planenaufb.
Ara
Durum: yeni, boş ağırlık: 12.300 kg, azami yük ağırlığı: 37.200 kg, toplam ağırlık: 49.500 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 9.300 mm, yükleme alanı genişliği: 2.480 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 R17.5, renk: gri, Donanım: ABS, Gooseneck:
- Gooseneck with rear chamfer approx. 750 mm x 10°
- 30 mm thick hardwood flooring
- 3 pairs of lashing rings
Dedpfx Afjtvfkfsveuu
Two-part steel ramps:
- One pair of galvanized two-part steel ramps approx. 3,185 x 1,420 x 1,250 mm with grating surface
- Ramps with hydraulically foldable ramp sections and hydraulic lifting system
- Maximum load per pair: 30,000 kg
Loading platform:
- Loading platform with rear chamfer approx. 1,000 mm x 8°
- Approx. 48 mm hardwood flooring, over the axles with checker plate surface
Axles and tires:
- BPW axles and suspension, two rigid axles, one self-steering axle
- Air suspension with lift and lower valve
- Self-steering axle with electro-magnetic reverse lockout, activated via reverse gear or manually
- Tires 235/75 R17.5 3PMSF
Accessories included:
- 1 spare wheel with holder
- TPMS tire pressure monitoring system according to ECE R 141
- 2" king pin
- One galvanized steel headboard
- Yellow-red air couplings on the galvanized connection rail at the front
- 4 chocks with holders on the headboard
- Mounting at the rear of the gooseneck for ALU drive-on ramps
- 3 height levels of aluminum planks
- Galvanized folding supports under the chamfer of the loading platform
- Height-adjustable tarpaulin frame (3,960 mm)
- Galvanized headboard with tensioning mechanism for sliding curtain
- Height adjustable by approx. 400 mm
- Roof brand "EDSCHA" sliding forward on ALU roof rail profiles, bolted to front and rear wall
- 3 pairs of sliding stakes in the loading platform
- Body rear left and right hydraulically extendable by approx. 750 mm
- Sliding roof with pivotable portal beam
- Sliding curtain with 700 mm reserve length, with tension belts at spacing approx. 600 mm
- Upper edge of structure approx. 3,960 mm high
- Driving with open sliding roof is not permitted and will cause damage to the curtain
- Cover plates for bridging the gap between ramps and loading platform
- Electro-hydraulic unit at the rear, beneath the loading platform
- At the gooseneck and at the ramps left and right each a bracket for warning panels incl. socket
- Control valves for the ramps positioned on the right trailer side
- 6 pairs of stake pockets for insertable stakes 100 x 50 mm in the outer frame of the loading platform
- Lift axle at the front axle
- Grating surface in the chamfer of the loading platform C40/4 (point load 3.4 t on an area of 20 x 20 cm)
- One INOX toolbox 565 x 290 x 810 mm on the right in driving direction between the axles
- On the checker plate on the gooseneck and loading platform, a painted sand layer for slip resistance
- Central lubrication system BEKAMAX (Pico) with standard lubricant NLGI-2 and removable guard around the pump
- Four warning panels extendable by approx. 400 mm, each approx. 423 x 423 mm, with position light
- Load pressure gauge for determining axle loads including load chart
- HRM metallization (High Resistance Metallization) of the outer frame
- Complete steel structure shot-blasted, then visible defined surfaces hot-finished with ZINACOR 850 metallization (zinc 85% - alu 15%)
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
Faymonville4-2+2-Achs-Tele-Semi m. Radmulden u. Rampen
Ara
Durum: yeni, boş ağırlık: 13.500 kg, azami yük ağırlığı: 51.500 kg, toplam ağırlık: 69.500 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 8.800 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 r17.5, renk: gri, Donanım: ABS, Gooseneck:
Gooseneck in SNT design for optimization of loading area length, length approx. 3,700 mm
Gooseneck rear with bevel approx. 1,000 mm x 10°
Loading Area:
Telescopic loading area, length approx. 8,800 mm, with rear incline approx. 500 mm x 10°
Recess in the incline and extending into the loading area for accommodating the excavator dipper stick
Pneumatic locking with conical pin and reinforced locking positions
The supply lines are protected within the extendable beam and adjust to the respective loading area length
Ramps:
1 pair of two-piece steel ramps, approx. 4,350 mm x 900 mm
Hydraulically folding ramp tips
Ramps can be hydraulically adjusted individually approx. 235 mm outwards and 215 mm inwards
Axles and Suspension:
BPW axles and suspension, two fixed axles, two steering trailing axles
Electromagnetic reverse lock activated via reverse gear and manually
Air suspension with lifting and lowering valve
Axle tool
Tyres: 235/75 R17.5 3PMSF twin tyres
Load index: 143/141J (144/144F)
Brake System:
WABCO brake system, EBS-E according to EU regulations
Lighting System:
24-volt lighting system, “ASPÖCK-NORDIK full LED”
Metallization:
Standard HRM metallization of the external frame
Complete steel structure shot blasted, subsequently visible defined surfaces metallized with ZINACOR 850 (zinc 85% - aluminium 15%) hot-finished
Steel Structure:
Steel grades:
S355J2+N/S355MC (yield strength 355MPa)
S690QL/S700MC (yield strength 690MPa)
Welders certified according to DIN-EN 287-1
MAG welding process according to EN ISO 4063
Shielding gas M21 according to EN ISO 14175
Included accessories:
Removable steel front wall, height approx. 400 mm
ASPÖCK-UNIBOX on the front connection strip with 24N, 24S & 15-pin sockets
24N connection according to ISO-1185
24S connection according to ISO-3731
15-pin connection according to ISO-12098
Round NATO socket on the front connection strip
Cable for supplying the electro-hydraulic pump and/or electric winch (35 mm², 3.5 m long) between trailer and tractor unit with plug (NATO-NATO)
3 kW electro-hydraulic unit for controlling hydraulic operations (except for hydraulic winches)
1 spare wheel with mounting adapter
External beams on the gooseneck with mounting holes for bolt-on lashing rings, first hole approx. 200 mm from the front, then approx. every 400 mm
2 pairs of screw-in lashing rings included
Mounting hole on the upper rear of the gooseneck external beam for a screw-on lashing ring
1 pair screw-in lashing rings
Approx. 40 mm thick hardwood floor above gooseneck
On the gooseneck, 1 pair of plug-in side aluminium drop sides, approx. 400 mm high, anodized
Djdpfjk Ahugox Afveuu
On the gooseneck, one plug-in aluminium rear wall, approx. 400 mm high, anodized
2" king pin
Guide plate on the gooseneck for the fifth wheel, approx. 500 mm wide
4 wheel chocks with holders
Provision for aluminium approach ramps
Mechanical landing gears with 2-speed gearbox and crank
On the loading area, continuous hardwood floor approx. 50 mm thick, interrupted only between the axles
Load area locking with conically welded positioning profiles every 250 mm including pre-tension plate
Slotted holes at the front of the loading area for attachable and repositionable bridging plates
1 intermediate table with recessed loading area, approx. 300 mm wide, for the large cross-section sliding tube with sheet metal covering
Front and rear with longe...
Küçük ilan
Dortmund
2.568 km
Düşük yükleyici
FaymonvilleMAX Trailer 4-Achs-Tele-Semi mit Rampen, zwgl.
Ara
Durum: yeni, boş ağırlık: 13.250 kg, azami yük ağırlığı: 47.550 kg, toplam ağırlık: 60.800 kg, dingil konfigürasyonu: 3 aks, süspansiyon: hava, lastik boyutu: 245/70 r17.5, renk: gri, Donanım: ABS, Gooseneck:
Gooseneck with rear taper approx. 750 mm x 10°.
3 pairs of lashing rings
30 mm thick hardwood flooring
Extendable loading platform:
Extendable loading platform with rear taper approx. 1,000 mm x 8°
5 pairs of outward-folding lashing rings
3 pairs of outward-folding lashing rings
1 pair of horizontal lashing rings at the front of the loading platform
Cutouts in the outer frame of the platform for attaching tension straps
Approx. 48 mm thick hardwood flooring, checker plate over the axles
Two-piece steel ramps:
One pair of galvanized two-piece steel ramps, approx. 2,750 + 1,400 x 800 mm, with approx. 48 mm thick hardwood decking.
Ramp with hydraulically folding ramp sections, hydraulic lift mechanism, and hydraulically adjustable. Maximum load per pair: 40,000 kg
Landing legs:
JOST landing legs (mechanical) with two-speed gearbox for 24 t lifting capacity (50 t test load)
Axles and tires:
BPW axles and suspension, 1st axle fixed, all other axles hydro-mechanically forced-steered
Technical axle load: 12,000 kg
Air suspension with lift and lower valve
Axle tool
Tires 245/70 R 17.5
Brake system:
Braking system according to EU regulations with EBS-E (4S3M) without connection lines to the tractor unit
Steel structure:
Steel structure made of high-strength fine-grain steels
Steel qualities:
S355J2+N/S355MC (yield strength 355 MPa)
S690QL/S700MC (yield strength 690 MPa)
Duodpfx Afjl Uxdkovsu
Paintwork:
First-class and durable corrosion protection of the standard shot-blasted welded frame, ensured by a two-component (2K) zinc dust primer
High-quality two-component (2K) topcoat in single-tone Nova Grey
Rear section metallized and painted in RAL 9010 (pure white)
No metallic paint possible
Electrical system:
Electrical system according to EU regulations, 24 Volt ASPÖCK-NORDIK (ASS3) lighting
ASPÖCK-UNIBOX at the front connection bar with 24N, 24S & 15-pin sockets
Connections according to ISO:
24N ISO-1185
24S ISO-3731
15-pin ISO-12098
Accessories included:
2" king pin
Galvanized steel front wall approx. 400 mm high
Yellow-red air couplings at the galvanized front connection bar
4 wheel chocks with holder at the front wall
One spare wheel with holder in front of the front wall
Electro-hydraulic unit
Remote steering front and rear via cable remote control with push buttons and single-track axle alignment control
Mount for ALU loading ramps at rear section of the gooseneck
European reflector boards (red-yellow) at the rear of the trailer
White reflector tape as per EU regulations on the side, extension and rear Red at the rear
At the gooseneck and ramps, one holder left and right for warning signs including socket
Beacon holder at the rear of the trailer
Galvanized folding support legs under the rear ramp of the loading area
Control valves for ramps located on the right side of the trailer
Cover plates to bridge the gap between ramp and loading platform
One mud flap at the rear of the trailer
Manual and description on USB stick
BEKAMAX (Pico) central lubrication system with standard NLGI-2 grease and removable protection for the pump
Plug-in ALU side and rear walls on the gooseneck approx. 2,440 x 400 mm
Rear galvanized plug-in posts are removable, superstructure length approx. 2,560 mm
One INOX toolbox 1,350x400x400 on the gooseneck, box covers oil fill plug
4 pairs of WADER container locks in the loading area for a
Küçük ilan
Dortmund
2.568 km
Düşük yükleyici
Faymonville3-Achs-Tiefbett-Pendelachsen-Bolzen-Laschenkupp.
Ara
Durum: yeni, boş ağırlık: 17.250 kg, azami yük ağırlığı: 48.700 kg, toplam ağırlık: 66.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 7.550 mm, yükleme alanı genişliği: 2.480 mm, yükleme alanı yüksekliği: 375 mm, lastik boyutu: 245/70 R 17.5, renk: gri, işletme ağırlığı: 17.250 kg, Donanım: ABS, Gooseneck:
- Gooseneck in SNT design for optimized load platform length, approximately 3,750 mm long
- Gooseneck hydraulically liftable/lowerable and detachable
- Suitable for tractor units: 6 x 4 and 8 x 4 (or 6 x 4 with optional 1-axle dolly)
Low bed:
- Low bed with external beams, configured as a telescopic vessel bridge in low construction with extension at the front
- Length x width approx. 7,550 mm x 2,740 mm
- Mechanical locking of the extension
Chassis:
- Rear chassis with closed outer frame
- Tread plate covering and continuous prismatic excavator recess approx. 1,450/900 x 505 mm, open at the rear
Axles, Suspension, and Tyres:
- “PENDEL-AXLE”, all axles hydromechanically forced steered
- Hose rupture valve on axle compensation cylinder with automatic RESET function
Duedpfxeh Hm Tzs Afveu
- Hydraulic cylinders with shut-off valves and locking pins for securing in raised position
- Final coating of axles with 2 layers of single-colour 2-component paint in "FAY-Grey-34-0260"
- Technical axle load 12,000 kg
- Hydraulic axle compensation
- 245/70 R 17.5 tyres
Accessories:
- Detachable steel front wall, approx. 400 mm high
- 4 wheel chocks
- Gooseneck closed at the rear upper section with a removable cover
- 1 pair of steel ramps with climbing strips and fixing bolts for bridging the low bed uptake hooks
- Ramps can be placed over or between the hooks
- Mounting points for steel loading ramps at the rear between the external beams of the gooseneck
- One locking position approximately every 1,000 mm on the extension
- 1 lashing ring each left and right on the front cross member
- Supply line connection strip to the tractor unit, fitted at the height of the outer frame profile
- 6 pairs of threaded blocks on the outside of the inner beams of the load platform for mounting screw-on M24 rings
- 6 pairs of recessed lashing rings on the outside of the outer beams of the load platform, foldable inwards and outwards
- 1 pair of threaded blocks at the front and rear of the outer beams of the load platform for mounting screw-on M24 rings
- Insertion strip for loose ALU approach ramps on the rear cross member of the vehicle
- Central lubrication system with 2 pumps, brand BEKAMAX
- Remote steering from front and rear, operable via cable remote control, with single-track control of axles
- 3 kW electro-hydraulic power pack for operating hydraulic functions, except hydraulic winches
- Removable load floor (galvanised), can be inserted in 3 elements between the outer beams, with hardwood covering
- Folding extensions, approx. 230 mm per side
- Loose widening boards, framed in steel
- 4 warning panels approx. 423 x 423 mm
- Radio remote control for remote steering operation
- 3.5" kingpin
- Anti-slip stickers on the left bevel of the gooseneck
- Hydraulic connections from the gooseneck to the low bed with multi-coupling instead of screw couplings
- Guiding plate from gooseneck for the fifth wheel plate, approx. 800 mm wide
- 1 spare wheel with mounting adapter
- Parking position on the gooseneck for warning panels when not in use
- 2 pairs of stanchion pockets recessed in the outer frame of the chassis for insertable stanchions approx. 100 x 50 mm
- Rear section of the chassis with a detachable plate closing the bucket arm recess at the rear
- Trailer colour MB 7350 Novagrau
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
FaymonvilleMAX Trailer 4-Achs-Tele-Semi-Rampen-nlla
Ara
Durum: yeni, azami yük ağırlığı: 49.000 kg, toplam ağırlık: 60.800 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 9.300 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 r 17.5, renk: gri, Donanım: ABS, Gooseneck:
- Gooseneck with front corners beveled at 45° and rear taper approx. 750 mm x 10°
- 3 pairs of lashing rings (LC 5,000 daN)
- 30 mm thick hardwood flooring
Extendable Loading Platform:
- Loading platform in extendable design with rear taper approx. 1,000 mm x 8°
- 5 pairs of outward folding lashing rings (LC 5,000 daN)
- 3 pairs of outward folding lashing rings (LC 10,000 daN)
- 1 pair of recessed lashing rings at the front of the loading platform (LC 10,000 daN)
- Cutouts in the outer frame of the loading platform for attaching tension belts (LC 2,000 daN)
- c. 48 mm thick hardwood flooring, over the axles with checker plate covering
Detachable Two-Part Ramps:
- One pair of galvanized, two-piece steel ramps, approx. 2,750 + 1,400 x 800 mm with approx. 48 mm thick hardwood covering
- Ramps with hydraulically folding ramp sections, hydraulic lifting unit and hydraulically adjustable
- Maximum load per pair: 40,000 kg
Landing Legs:
- JOST landing legs (mechanical) with 2-speed gearbox for 24t lifting capacity (50t test load)
Axles and Tyres:
- BPW axles, two rigid axles, two steering trailing axles, air suspension, with drum brakes, with raise/lower function
- The trailing steering axles can be locked electromagnetically via reverse gear or manually
- Axle tools
- Tyres: 235/75 R 17.5
Brake System:
- Brake system according to EU regulations with EBS-E (4S3M)
Steel Construction:
- Steel construction made of high-tensile fine-grained steels
- Steel grades:
- S355J2+N/S355MC (yield strength 355 MPa)
- S690QL/S700MC (yield strength 690 MPa)
Paintwork:
Dodpfjh Etf Rox Afvjuu
- First-class and durable corrosion protection of the standard shot-blasted welded frame, ensured by a 2-component (2K) zinc dust primer
- High-quality 2-component (2K) top coat finish in single-colour Novagrau
Electrical System:
- Electrical system according to EU regulations, lighting 24 Volt ASPÖCK-NORDIK (ASS3)
- ASPÖCK-UNIBOX on the front terminal strip with 24N, 24S & 15-pin sockets
Accessories Included:
- 2" king pin
- One galvanized steel front wall approx. 400 mm high
- One spare wheel with holder in front of the headboard
- Yellow-red air couplings at the galvanized front terminal strip
- 4 chocks with holder at the front wall
- Mounting at the rear area of the gooseneck for ALU drive-on ramps
- Galvanized folding supports under the taper of the loading platform
- Bracket for a rotating beacon
- Cover plates to bridge the gap between ramps and loading platform
- White reflector tape to EU specification on the sides, red at rear and on extension
- Electro-hydraulic power pack
- On both sides of the gooseneck and ramps, mounting brackets for warning signs incl. socket outlet
- Ramp control valves installed on the right trailer side
- One mudguard at the rear of the trailer
- Instruction manual and description on USB stick
- ALU side walls and end wall, plug-in, on gooseneck approx. 2,440 x 400 mm
- The rear galvanized plug-in posts are removable (length of structure approx. 2,560 mm)
- 4 pairs of WADER container pockets in the loading platform for one 20ft, 2x 20ft or one 40ft container
- 7 pairs of stake pockets for 100 x 50 mm plug-in posts in the outer frame of the loading platform
- Extensions, galvanized, extendable by approx. 230 mm per side
- Lift axle on the front axle with control
- Square climbing rails 20 x 20 mm
- Central lubrication system BEKAMAX
- F
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
FaymonvilleMAX Trailer 2-Achs-Tiefbett mit Pendelachsen
Ara
Durum: yeni, boş ağırlık: 12.900 kg, azami yük ağırlığı: 34.100 kg, toplam ağırlık: 47.000 kg, dingil konfigürasyonu: 2 dingil, yükleme alanı uzunluğu: 6.850 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 350 mm, süspansiyon: diğer, lastik boyutu: 245/70 R 17,5, renk: gri, işletme ağırlığı: 12.900 kg, Donanım: ABS, Gooseneck:
- Gooseneck in SNT design for optimized loading area length, approx. 3,750 mm long
- Gooseneck hydraulically height-adjustable and detachable
- Technical fifth wheel load: 23,000 kg
- Suitable for tractor units: 4 x 2, 6 x 2, and 6 x 4
Loading Platform:
- Low bed with external beams in extendable "SUPER LOW" design, length approx. 6,850 mm
- Low bed with fixed hardwood floor approx. 40 mm thick and mechanical locking
Rear Chassis:
- Rear chassis with closed outer frame, checker plate covering and continuous prismatic excavator trough approx. 1,250/700 x 505 mm, open at the rear
- 2 pairs of lashing rings foldable outward
- 1 pair of lashing rings lying in the trough
- 2 pairs of stake pockets for plug-in stakes (100 x 50 mm) in the outer frame
Pendulum Axle and Tires:
- "PENDULUM AXLE", all axles hydromechanically forced-steered
- Hose rupture valve on axle compensation cylinder with automatic RESET function
- Hydraulic cylinders with shut-off valves and pre-insert to secure in lifted position
- Final coating of axles with 2 layers of single-color 2K paint, painted in "FAY-Grey-34-0260"
Dedjhlz R Sspfx Afvsuu
- Technical axle load: 12,000 kg
- Hydraulic axle compensation
- Tires 245/70 R17.5
- TPMS (Tire Pressure Monitoring System) compliant with ECE R 141
Accessories:
- Prepared for fitting of bolted container locking positions for 1x 20ft or 1x 40ft container on the external beams
- 2" kingpin
- Galvanized steel front wall approx. 400 mm high
- One spare wheel
- On the galvanized connection strip at the front: yellow-red air couplings
- 4 wheel chocks
- Remote steering front and rear operable via cable remote control with push buttons, including single-track monitoring of the axles
- Hydraulic connections from gooseneck to low bed with multi-coupling instead of threaded couplings
- Electro-hydraulic unit
- White reflector tape on sides, extension and rear, according to EU regulations
- European reflector panels (red-yellow) at the rear of the trailer
- At the gooseneck and rear panel, left and right, each with a bracket for warning signs including socket
- 6 pairs of threaded blocks between the lashing rings under the top chord on the outer beam for mounting of bolt-on RUD rings VLBG-4
- Removable ALU side walls and rear wall on the gooseneck, approx. 2,440 x 400 mm
- Rear galvanized plug-in posts are removable (body length approx. 2,560 mm)
- Gooseneck at the upper rear area closed with a removable cover
- 5 pairs of stake pockets for plug-in stakes 100 x 50 mm in the outer frame of the loading platform
- Fold-out extensions, approx. 230 mm per side
- 2 pairs of bolt-on RUD rings VLBG-4 M24 (LC 8,000 daN)
- 1 pair of steel ramps for bridging the low bed’s mounting hooks
- Sanded layer painted on the loading platform as an anti-slip coating
- Speed stickers 80 km/h on rear and both sides
- Rear chassis’ bucket recess at the rear closed with a plug-in plate
- Four warning panels extendable by approx. 400 mm, size approx. 423 x 423 mm
- Radio remote control for the rear steering, in addition to the cable remote control, with indicator lights on the receiver as single-track monitoring
- Central lubrication system with 2 BEKAMAX (Pico) pumps using standard grease NLGI-2
- Load gauge for determining axle loads
- HRM (High Resistance Metallisation) of the outer frame
- Complete steel construction shot-blasted, then all defined visible surfaces hot-finished in metallization with ZINACOR 850 (Zinc 85% - Alu 15%)
Küçük ilan
Dortmund
2.568 km
Alçak şasi dorse
Faymonville4-1+3-A-Tele-Semi-Radmul.-Rampen-Gummibe
Ara
Durum: yeni, boş ağırlık: 14.350 kg, azami yük ağırlığı: 53.450 kg, toplam ağırlık: 67.800 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 8.800 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75 R 17,5, renk: gri, Donanım: ABS, hidrolik arka platform, Gooseneck:
- Gooseneck in SNT design to optimize the loading deck length, length approx. 3,700 mm
- Gooseneck rear with chamfer approx. 1,000 mm x 10°
- Suitable for tractor units: 6x2, 6x4, 8x4 short
Loading Platform:
- Loading platform with extendable design, length approx. 8,800 mm, with rear chamfer approx. 500 mm x 10°
- Recess in the loading platform as well as extending into the chamfer for accommodating the excavator dipper stick, approx. 3,850 x 750 x 210/290 mm
Two-Part Steel Ramps:
- One pair of two-part steel ramps, each approx. 4,350 mm long and approx. 900 mm wide
- Ramps with rubber covering
- Ramps can be hydraulically adjusted individually approx. 235 mm outward and approx. 215 mm inward
- "Super Grip" rubber flooring 25 mm and steel plate flooring approx. 5 mm as additional reinforcement on the chamfer of the platform
- Square climbing strips 20 x 30 mm, approx. every 200 mm on the outer frame of the ramp
Axles, suspension, and tires:
- BPW axles and suspension, 1st axle steered, all other axles forced steered hydromechanically
- Technical axle load: 12,000 kg
- 1st axle with electromagnetic reversing lock, can be activated via reverse gear and manually
- Air suspension with lifting and lowering valve
- Tires 235/75 R 17.5
- TPMS tire pressure monitoring system compliant with ECE R141
- TPMS tire pressure sensors fitted on all wheels including spare wheels
Surface Treatment:
- Complete steel construction automatically shot-blasted with blasting machine after welding
- Second blasting process with corundum for optimal adhesion of the coating system
Dujdsya E A Njpfx Afvju
- HRM metallization of the entire vehicle chassis with ZINACOR 850 (85% zinc/15% aluminum) to ensure best possible corrosion protection
- Final coating with 2 layers of single-color 2-component topcoat in MB 7350 Novagrau
Included Accessories:
- Steel front wall, plug-in, approx. 400 mm high
- 3kW electric-hydraulic power unit for hydraulic controls, except for hydraulic winches
- 1 spare wheel
- External beam on gooseneck with mounting holes for screwable lashing rings
- First hole approx. 200 mm from the front, then approx. every 400 mm
- 2 pairs of screw-in lashing rings included
- 1 pair of horizontal lashing rings at the rear area of the gooseneck
- On the gooseneck, 1 pair of plug-in ALU side boards, approx. 400 mm high, anodized
- On the gooseneck, 1 plug-in ALU rear board, approx. 400 mm high, anodized
- Approx. 40 mm thick hardwood floor on the gooseneck, checker plate at the king pin area
- 2" king pin
- Round NATO socket at the front connector strip
- 4 wheel chocks
- 1 intermediate table, approx. 300 mm wide
- 1 pair of lashing rings on the front cross beam
- 8 pairs of recessed lashing rings in the outer frame of the loading platform, foldable outward
- Extensions (galvanized) extendable by approx. 230 mm per side
- Wheel recesses with square climbing strips, 15 x 15 mm, continuously open in front of the axles up to the cross beam of the gooseneck, approx. 700 x 410 mm
- Wheel recesses with square climbing strips, 15 x 15 mm, between the 1st and 2nd axle, approx. 1,480 x 700 x 410 mm
- ALU covers for the wheel recesses, also usable as bridging elements for the extension or as extension beams
- 1 pair of mechanical rear supports
- Remote control (radio and cable)
- Lifting axle at the front axle
- Square climbing strips 20 x 30 mm, approx. every 200 mm
- Central lubrication system with 1 pump
- Wabco Smart Board system
- 4 warning boards, approx. 423 x 423 mm
Küçük ilan
Dortmund
2.568 km
Platform
FaymonvilleMAX Trailer 3-Achs-Tele-Plateau-zwangsg.
Ara
Durum: yeni, boş ağırlık: 9.300 kg, azami yük ağırlığı: 38.700 kg, toplam ağırlık: 48.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 13.600 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 1.200 mm, süspansiyon: hava, lastik boyutu: 385/65 R 22,5, renk: gri-siyah, Donanım: ABS, Loading Platform:
• Loading platform in extendable design with pneumatically operated locking mechanism
• Loading platform with approx. 30 mm thick wooden floor
• 7 pairs of outward-folding lashing rings (LC 5,000 daN)
• 3 pairs of outward-folding lashing rings (LC 10,000 daN)
• Cut-outs in the outer frame of the loading platform for attaching tension straps (LC 2,000 daN)
Axles and Tyres:
• BPW axles and suspension, all axles hydro-mechanically forced steered
• Equipped with disc brakes
• Technical axle load: 10,000 kg
• Air suspension with raise/lower valve
• Axle tools
• Tyres: 385/65 R 22.5
• TPMS (Tyre Pressure Monitoring System) according to ECE R 141
Brake System:
• WABCO brake system compliant with EU regulations, with EBS-E (2S2M)
Electrical System:
• Electrical system according to EU regulations, lighting 24 Volt ASPÖCK-NORDIK (ASS3)
• ASPÖCK-UNIBOX on the front connection bar with sockets 24N, 24S & 15-pin
• Connections according to ISO standards
• 24N ISO-1185
• 24S ISO-3731
• 15-pin ISO-12098
Accessories Included:
Dusdoiu Etrspfx Afvou
• Remote-controlled steering from front and rear via cable remote with push-button operation, including single-track monitoring of axles
• 4 wheel chocks with holders mounted on the front wall
• 2" kingpin
• One galvanized steel front wall approx. 1,600 mm high
• Yellow-red air couplings mounted on the galvanized front connection bar
• White reflective tape according to EU regulations on the sides, at extension and at the rear of the trailer in red
• European reflective plates (red-yellow) on the rear of the trailer
• One mudflap at the rear of the trailer
• Manual and description
• Mounting bracket for a beacon at the rear of the trailer
• Loading platform with approx. 30 mm thick wooden floor enclosed in omega profiles
• 10 pairs of stake pockets for plug-in stanchions 100 x 50 mm in the outer frame of the loading platform
• 1 spare wheel holder under the right side of the loading platform in the direction of travel
• Electro-hydraulic unit
• On the gooseneck and rear apron left and right, each with a bracket for warning boards including socket
• Painted sand layer for anti-slip protection on the main beam
• 6 pairs of WADER container locks on the loading platform, for 1x20ft, 2x 20ft, or 1x 40ft container; in the extension, an additional locking position is provided for a 45ft container
• 4 pairs of crosswise mounted stake pocket bars on the loading platform for plug-in stanchions 100 x 50 mm
• Access ladder mounted on the right in the direction of travel
• One HDPE toolbox approx. 1,200 x 500 x 480 mm in front under the loading platform on the left in the direction of travel
• BEKAMAX central lubrication system (Pico) with removable pump guard
• Lift axle on the front axle controlled by TEBS E depending on current axle load and loading condition
• Wireless remote control for the rear steering in addition to the cable remote, with indicator lights on the receiver for single-track monitoring
• Four extendable warning plates approx. 400 mm extension, size approx. 423 x 423 mm with position light
• Bracket for beacon on the warning plates
• 80 km/h speed stickers on the rear and both sides
• Load pressure gauge to determine axle loads, including load diagram
• HRM metallization (High Resistance Metallisation) of the outer frame
• Complete steel construction shot-blasted, then the defined visible surfaces metallized with ZINACOR 850 (zinc 85% - aluminium 15%) hot-finished
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
Faymonville6-Achs-Tele-Semi mit PA-X Achssystem
Ara
Durum: yeni, boş ağırlık: 22.700 kg, azami yük ağırlığı: 79.300 kg, toplam ağırlık: 102.000 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 11.000 mm, yükleme alanı genişliği: 2.850 mm, yükleme alanı yüksekliği: 920 mm, lastik boyutu: 245/70 R 17.5, renk: gri, işletme ağırlığı: 22.700 kg, Donanım: ABS, Gooseneck:
- Gooseneck in SNT design for optimized loading deck length, approximately 3,750 mm long, with rear tapering of about 850 mm x 10°
- Hydraulically liftable and lowerable, stroke ± 250 mm including hydraulic connection linked to the hydraulic axle compensation of the first two axles
- Open in the rear third
- For tractor units: 6x4 and 8x4
Loading Platform:
- Extendable loading platform, length approx. 11,000 mm with rear taper approx. 500 mm x 10°
- A recess in the platform and into the taper for accommodating the excavator bucket arm, approx. 4,240 x 900 x 440 mm
- Pneumatic locking with conical locking bolt and reinforced locking positions; supply lines are protected in the extendable beams and automatically adapt to the respective platform length
Ramps:
- One pair of two-part steel ramps, approx. 4,650 mm long and approx. 900 mm wide
- Hydraulically folding ramp tips
- Ramps individually hydraulically adjustable approx. 235 mm outwards and approx. 215 mm inwards
- "Super Grip" rubber flooring 25 mm and approx. 5 mm steel flooring as additional reinforcement on the tapered section of the platform
- Square climbing strips 20x30 mm, spaced approx. every 200 mm on the outer frame of the ramp
Axles, Suspension and Tyres:
- PA-X axle system, all axles forced steered hydro-mechanically
- Steering behavior of the first two axles can be optimally adjusted to the platform length both mechanically and hydraulically
- Hose rupture valve on the axle compensation cylinder with automatic RESET function
- Hydraulic cylinders with shut-off valves and pilot pin for securing in raised position
- 245/70 R 17.5 3PMSF
Accessories Included:
- Removable steel front wall, approx. 400 mm high
- Supply line connection strip to tractor unit, mounted at the height of the outer frame profile
- 1 spare wheel
- Outer beams of the gooseneck with mounting holes for screwable lashing rings
- The first hole approx. 200 mm from the front, then spaced approx. every 400 mm
- 2 pairs of screw-in lashing rings included
- Checker plate covering over the gooseneck
- 1 pair of removable ALU sideboards approx. 400 mm high, anodized, mounted on the gooseneck
- Removable rear ALU wall on the gooseneck, approx. 400 mm high, anodized
- 3.5" king pin / 2" king pin fitted
- Guide plate on the gooseneck for the fifth wheel, approx. 500 mm wide
- 4 wheel chocks
- 4 axle load gauges
- Mechanical fixed support legs at the front
- 1 one-piece INOX toolbox, approx. 2,480 x 340 x 390 mm
- Mechanical fixed support legs at the front
- Continuous steel sheet flooring with painted-in sand layer on the platform for anti-slip protection
- 1 intermediate table, approx. 500 mm wide, for the extending section, with elongated holes for suspended and adjustable bridging elements
- Painted sand coating on the supporting surfaces of the intermediate table
- Mechanical locking for securing the intermediate table in the extended position
Duedpfx Afjk Af Svsvju
- 8 pairs of stake pockets in the outer frame
- Extendable (galvanized) widening units approx. 230 mm per side
- 1 pair of hydraulic rear supports
- Central lubrication system
- 1 reversing light each left and right at the rear of the vehicle
- 3 kW electro-hydraulic power unit
- Widening boards, loose, in reinforced steel U-frame
- Radio and cable remote control
- 4 warning panels, approx. 423 x 423 mm
Küçük ilan
Dortmund
2.568 km
Düşük yükleyici
Faymonville5-Achs-Tele-Semi m. hydr. Rampen
Ara
Durum: yeni, boş ağırlık: 15.900 kg, azami yük ağırlığı: 63.500 kg, toplam ağırlık: 68.000 kg, dingil konfigürasyonu: 3 aks, yükleme alanı uzunluğu: 12.700 mm, yükleme alanı genişliği: 2.740 mm, yükleme alanı yüksekliği: 860 mm, süspansiyon: hava, lastik boyutu: 235/75/r17,5, renk: gri, işletme ağırlığı: 52.100 kg, Donanım: ABS, Gooseneck:
Gooseneck in SNT design to optimize loading platform length, approx. 3,300 mm long, with rear taper approx. 1,000 mm x 10°
Technical fifth wheel load: 23,000 kg
For tractor units: 6x2, 6x4 and 8x4
Loading Platform:
Telescopic loading platform, length approx. 9,400 mm, with rear taper approx. 500 mm x 10°
A recess integrated into the platform and extending into the incline to accommodate the excavator bucket stick approx. 3,850 x 950 x 210/290 mm
Pneumatic locking with tapered locking pins and reinforced locking positions; supply lines are routed safely inside the extendable beams and automatically adapt to the current platform length
Dodpfomfqi Ijx Afvjuu
Axles and Tyres:
BPW axles and suspension, 1st axle fixed, all other axles hydro-mechanically forced steered
Technical axle load: 12,000 kg
Air suspension with lift and lower valve
Axle tool
235/75 R 17.5 3PMSF twin tyres
Load index 143/141J (144/144F)
Two-part Steel Ramps:
One pair of two-part steel ramps, approx. 4,350 mm long and 900 mm wide
Hardwood covering
Hydraulically folding ramp tips
Ramps hydraulically adjustable individually: approx. 235 mm outward, approx. 215 mm inward
Braking System:
WABCO EBS-E brake system in compliance with EU regulations
Sockets and Lighting:
24-volt lighting system
Full Metallization:
Complete HRM metallization with ZINACOR 850 for optimal corrosion protection
Surface Treatment:
Entire steel structure shot-blasted automatically after welding using a blast wheel
Second blasting with corundum for optimal coating adhesion
Final coating with two layers of two-component paint (single colour, Nova grey), then cavity sealing with special wax
Rims in silver grey
Steel Structure:
Steel structure made from high-tensile fine-grained steels
Steel grades: S355J2+N/S355MC, S690QL/S700MC
Accessories:
Plug-in steel front wall, approx. 400 mm high
Connection strip for supply lines to the tractor unit
Spiral cable for supplying the electro-hydraulic unit and/or electric winch between trailer and tractor unit with plug for electro-hydraulic unit for hydraulic control functions, except hydraulic winches
Outer beam of gooseneck with mounting holes for bolted lashing rings
First hole approx. 200 mm from the front, then every approx. 400 mm
One mounting hole at the upper rear portion of gooseneck outer beam for a bolted lashing ring
Approx. 40 mm thick hardwood flooring above the gooseneck, chequer plate over kingpin area
Gooseneck guide plate for the saddle plate, approx. 500 mm wide
Continuous hardwood flooring (approx. 50 mm thick) over the loading platform, interrupted between the axles
Locking of the loading platform using welded conical locking profiles every 250 mm, including pre-tension plate
Oblong holes for insertable and repositionable bridging elements: on the fixed section behind the gooseneck at the front of the platform
1 sliding intermediate table for the telescopic tube with large cross-section
Operating valves for hydraulic ramps on right side of vehicle
Central lubrication system with 1 pump, standard grease according to NLGI-2
Radio remote control for steering override operation, in addition to cable remote, with 2 indicator lights on receiver for one-track monitoring
Küçük ilan
Dortmund
2.568 km
Alçak yükleyici
FaymonvilleMAX Trailer 3-Achs-Mega-Tele-Plateau-zwangsgel.
Ara
Durum: yeni, boş ağırlık: 10.600 kg, azami yük ağırlığı: 35.400 kg, toplam ağırlık: 45.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 13.500 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 940 mm, süspansiyon: hava, lastik boyutu: 235/75 R 17,5, renk: gri, Donanım: ABS, Loading platform:
- Loading platform with extendable design
- Loading platform with hardwood planks, approx. 500 mm x 8° rear chamfer
- 2 pairs of lashing rings (LC 5,000 daN)
- 1 pair of lashing rings (LC 10,000 daN)
- 6 pairs of outward-folding lashing rings (LC 5,000 daN)
- 3 pairs of outward-folding lashing rings (LC 10,000 daN)
- Cut-outs in the outer frame of the loading platform for attaching tension straps
Brake system:
- Brake system compliant with EU regulations with EBS-E (2S2M)
Paintwork:
- First-class and durable corrosion protection of the standard shot-blasted welded frame, guaranteed by a 2-component (2K) zinc dust primer
- High-quality 2-component (2K) topcoat, single-color in Novagrau (Nova grey)
- Rear section metallized and painted in RAL 9010 (Pure White)
- Metallic paint not available
Landing legs:
- JOST landing legs (mechanical) with 2-speed gearbox for 24t lifting capacity (50t test load)
Steel construction:
- Steel construction made of high-strength fine-grained steels
- Steel grades:
- S355J2+N/S355MC (yield strength 355MPa)
- S690QL/S700MC (yield strength 690MPa)
Electrical system:
- Electrical system according to EU regulations, LED lighting 24 Volt
Duodpfx Asl Ux Rwjfvju
- Sockets: 2x 7-pin & 1x 15-pin
Axles and tires:
- BPW axles, air-suspended, with disc brakes (377 mm), with lift/lower function
- Hydro-mechanically forced steering
- Axle tool kit
- Twin tires 235/75 R 17.5
Included accessories:
- Yellow-red air couplings on the galvanized front connection rail
- 4 chocks with holders
- 2" king pin
- Galvanized steel front wall approx. 1600 mm high
- White reflective tape as per EU regulations on sides, extension, and rear in red
- Loading platform with heavy-duty hardwood floor
- Steering from front and rear via cable
- Remote control via push buttons with single-track axle monitoring
- Radio remote control for auxiliary steering
- 9 pairs of stake pockets for plug-in stanchions 100 x 50 mm in the outer frame of the loading platform
- Galvanized folding supports under the loading platform chamfer
- Sliding hook-in rail for ALU ramps at the rear of the vehicle
- European reflective signs (red-yellow) at the rear of the trailer
- One mudflap at the rear of the trailer
- One bracket for a rotating beacon at the rear of the trailer
- On the gooseneck and on the left/right rear panel each: one holder for warning signs including socket
- INOX toolbox 1,500 x 390 x 810 under the loading platform on the right (direction of travel)
- BEKAMAX (Pico) central lubrication system with standard grease NLHI-2 and removable guard for the pump
- 6 pairs of WADER container locks in the loading platform, for 1x 20ft container, 2x 20ft container, or 1x 40ft container, with additional locking point in the extension for a 45ft container
- 4 pairs of cross-mounted stake pocket rails in the loading platform, for plug-in stanchions 100 x 50 mm
- Lift axle at the front axle with TEBS-controlled adjustment, depending on current axle load and loading status
- Speed stickers 80 km/h at rear and both sides
- Four warning signs extendable by approx. 400 mm, approx. 423 x 423 mm, with LED position light
- Holder for rotating beacon on warning signs
- Load pressure gauge for axle load determination, including load diagram
- HRM metallization (High Resistance Metallisation) of the outer frame
- Complete steel construction shot-blasted, then defined visible areas hot-finished metallized with ZINACOR 850 (Zinc 85% - Alu 15%)
Küçük ilan
Dortmund
2.568 km
Platform
FaymonvilleMAX Trailer 3-Achs-Mega-Tele-Plateau-Radmulden
Ara
Durum: yeni, boş ağırlık: 9.500 kg, azami yük ağırlığı: 35.500 kg, toplam ağırlık: 45.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 13.500 mm, yükleme alanı genişliği: 2.540 mm, süspansiyon: hava, lastik boyutu: 435/50 R 19.5, renk: gri, işletme ağırlığı: 9.500 kg, Donanım: ABS, Loading platform in extendable design:
Loading platform with hardwood floorboards, rear chamfer approx. 1,000 mm x 8°
1 pair of fixed wheel recesses, approx. 1,610 x 970 x 400 mm
2 pairs of lashing rings (LC 5,000 daN)
1 pair of lashing rings (LC 10,000 daN)
6 pairs of folding external lashing rings (LC 5,000 daN)
2 pairs of folding external lashing rings (LC 10,000 daN)
Cut-outs in the outer frame of the loading platform for hooking in tensioning straps (LC 2,000 daN)
Braking system:
Braking system in accordance with EU regulations with EBS-E (2S2M)
Paintwork:
Premium, durable corrosion protection for the standard shot-blasted welded frame guaranteed by a 2-component (2K) zinc dust primer
High-quality single-color 2-component (2K) top coat in Novagrau
Rear section metallised and painted in RAL 9010 (pure white)
No metallic effect paint possible
Landing legs:
JOST landing legs (mechanical) with 2-speed gearbox for 24t lifting capacity (50t test load)
Steel construction:
Steel construction made of high-strength fine-grain steels
Steel grades:
S355J2+N/S355MC (yield strength 355MPa)
Duodpfx Afek Eammovou
S690QL/S700MC (yield strength 690MPa)
Electrical system:
Electrical system in accordance with EU regulations, 24 volt lighting
Sockets: 24N, 24S & 15-pin
Axles and tires:
BPW axles, air suspension, disc brakes (377 mm), with lift/lower function
The trailing steering axles can be locked for reversing by electro-magnetic control via reverse gear or manually
Axle tools
Tires 435/50 R 19.5
Accessories included:
At the front galvanized connection rail, yellow-red air couplings
4 wheel chocks with holders
2" king pin
Galvanized steel front wall, approx. 1600 mm high, EN12642-XL
White reflective tape to EU standards on the sides, on the extension, and red at the rear
Loading area with heavy-duty hardwood flooring
9 pairs of stake pockets for 100 x 50 mm plug-in stakes in the outer frame of the loading platform
1 spare wheel holder under the loading platform, right side of direction of travel
Galvanized drop-down supports under the loading platform chamfer
Sliding hook-in strips for ALU loading ramps at the rear of the vehicle
European reflective signs (red-yellow) at the rear of the trailer
A mudflap at the rear of the trailer
A bracket for a rotating beacon at the rear of the trailer
On the gooseneck and rear panel, left and right, each with a bracket for warning signs including socket
1 HDPE toolbox 620x360x610 under the loading platform, left side of direction of travel
4 pairs of WADER container locks in the loading platform for 1x 20ft container or 1x 40ft container; the extension is prepared with an additional locking position for a 45ft container
3 pairs of crosswise stake pocket strips mounted in the loading platform for 100 x 50 mm plug-in stakes
Lift axle on the front axle with control via TEBS E depending on current axle load and load status
Speed stickers 80 km/h at the rear and on both sides
Four warning panels, extendable by approx. 400 mm, approx. 423 x 423 mm, with LED position light. Each warning panel with a bracket for revolving beacon
Load gauge for determining axle loads including load chart
HRM metallization (High Resistance Metallisation) of the outer frame
Complete steel construction shot-blasted, then the defined visible surfaces are metallised
Küçük ilan
Dortmund
2.568 km
Platform
FaymonvilleMAX Trailer 3-Achs-Doppeltele-Plateau zwangsgel.
Ara
Durum: yeni, boş ağırlık: 11.300 kg, azami yük ağırlığı: 36.700 kg, toplam ağırlık: 48.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 13.600 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 1.250 mm, süspansiyon: hava, lastik boyutu: 385/65 r 22,5, renk: gri-siyah, Donanım: ABS, Loading Area:
Extendable loading platform with pneumatically operated locking mechanism
A fixed intermediate table approx. 250 mm wide is mounted on the central beam
8 pairs of folding lashing rings (LC 5,000 daN)
3 pairs of folding lashing rings (LC 10,000 daN)
Cut-outs in the outer frame of the loading area for hooking in tension straps (LC 2,000 daN)
Axles and Tyres:
BPW axles and suspension, all axles hydromechanically forced-steered
Disc brakes, technical axle load: 10,000 kg
Air suspension with lift and lower valve
Axle tool kit
6 tyres 385/65 R 22.5
Brake System:
Brake system according to EU regulations with EBS-E (2S2M)
Landing Legs:
JOST mechanical landing legs with 2-speed gearbox for 24 t lifting capacity (50 t test load)
Steel Construction:
Steel construction made of high-strength fine-grained steels
Steel grades:
S355J2+N/S355MC (yield strength 355 MPa)
S690QL/S700MC (yield strength 690 MPa)
Electrical System:
Electrical system in line with EU regulations, lighting 24 Volt ASPÖCK-NORDIK (ASS3)
ASPÖCK-UNIBOX on the front connection bar with 24N, 24S, and 15-pin sockets
Connections per ISO:
24N ISO-1185
24S ISO-3731
15-pin ISO-12098
Painting:
Top-class and durable corrosion protection of the standard shot-blasted welded frame provided by a 2-component (2K) zinc-rich primer
High-quality 2-component (2K) top coat in single-colour Nova Grey
Rear end metallised and painted in RAL 9010 (pure white)
Metallic paint not available
Included Accessories:
One bracket for warning signs, each at the gooseneck and the rear end plate, left and right, including socket
Remote steering operated from front and rear using cable remote control with push-buttons, with single-track alignment of the axles
Electro-hydraulic power pack
4 wheel chocks with holder on the front bulkhead
2" kingpin
One galvanised steel headboard approx. 2,200 mm high
Yellow-red pneumatic couplings on the galvanised connection rail at the front
White reflective tape per EU regulations on the sides, on the extension, and red at the rear
European reflective warning plates (red-yellow) at the rear of the trailer
One mud flap at the rear of the trailer
Manual and documentation
Bracket for revolving beacon at the rear of the trailer
Loading surface with approx. 30 mm thick wooden floor embedded in Omega profiles
10 pairs of stanchion pockets for plug-in stanchions 100 x 50 mm in the outer frame of the loading area
1 spare wheel holder under the loading platform on the right in the direction of travel
6 pairs of WADER container pockets in the loading area, for 1x 20ft container, 2x 20ft containers, or 1x 40ft container; an additional locking point in the extension is provided for a 45ft container
5 pairs of cross-mounted stanchion pocket rails in the loading area for plug-in stanchions 100 x 50 mm
Dsdpfx Ashlz Shofveuu
One galvanised bracket crosswise under the loading platform (2,390 x 720 x 400 mm)
Entry ladder mounted on the right side in the direction of travel
HDPE toolbox 1,200 x 500 x 480 mounted at the front under the loading surface on the left in the direction of travel
Lifting axle on front axle, control by TEBS E depending on current axle load and load status
Central lubrication system with 2 BEKAMAX (Pico) pumps with NLGI-2 general-purpose grease and removable guarding around the pump
Red/white reflective tape in the loading platform extension
A sand layer painted on the central beam as anti-slip protection
Radio remote control for rear steering in addition to cable remote, with in
Küçük ilan
Dortmund
2.568 km
Platform
FaymonvilleMAX Trailer 3-Achs-Mega-Tele-Plateau-nachlaufgel.
Ara
Durum: yeni, boş ağırlık: 8.300 kg, azami yük ağırlığı: 36.700 kg, toplam ağırlık: 45.000 kg, dingil konfigürasyonu: 3 dingil, yükleme alanı uzunluğu: 13.600 mm, yükleme alanı genişliği: 2.540 mm, yükleme alanı yüksekliği: 1.080 mm, süspansiyon: hava, lastik boyutu: 385/65 R 22.5, renk: gri, Donanım: ABS, hidrolik arka platform, Loading Area:
Loading area, extendable design with pneumatically operated locking mechanism
Cut-outs in the outer frame of the loading area for securing straps to be hooked in
Landing Gear:
JOST landing gear (mechanical) with 2-speed gearbox for 24t lifting capacity
Axles and Tyres:
BPW axles, air-suspended, with disc brakes (430 mm), equipped with raise/lower function
Trailing steering axle with electro-magnetic reversing lock, activated via reverse gear or manually
Axle tool kit
Tyres: 385/65 R 22.5
Brake System:
WABCO brake system compliant with EU regulations, with EBS-E
Paintwork:
Superior and durable corrosion protection for the standard shot-blasted welded frame, guaranteed by a two-component (2K) zinc-rich primer
High-quality two-component top coat, single-tone in MB 7350 Novagrau
tail section metallized and painted in RAL 9010
Metallic paint not possible
Steel Construction:
Steel construction made from high-strength fine-grained steels
Steel grades:
S355J2+N / S355MC
S690QL / S700MC
Electrical System:
Electrical system according to EU regulations
24 Volt ASPÖCK-NORDIK lighting
ASPÖCK-UNIBOX at the front connection strip with 24N, 24S & 15-pin sockets
Connections according to ISO
Accessories Included:
Front galvanized connection strip with yellow-red air couplings
Galvanized steel front bulkhead approx. 1,600 mm high, EN12642-XL
4 wheel chocks with brackets
Dodpfx Aoikyh Hefveuu
White reflective tape on the sides, on the extension, and rear red tape according to EU regulations
European reflector plates at the rear of the trailer
Approx. 30 mm thick hardwood floor, enclosed in omega profiles
10 pairs of stake pockets for 100 x 50 mm insert stakes in the outer frame
1 spare wheel carrier beneath the loading area, right side (in driving direction)
Manual and operating instructions
Bracket for rotating beacon at the rear of the trailer
On the gooseneck and rear plate, left and right: bracket for warning signs including socket outlets
Central chassis with painted sand coating as anti-slip protection
6 pairs of WADER container pockets in the loading area: for 1x 20ft container, 2x 20ft containers, or for 1x 40ft container in the extension, an additional locking point is provided for a 45ft container
4 pairs of crosswise stake pocket strips mounted in the loading area, for insert stakes 100 x 50 mm
One galvanized crosswise bracket underneath the loading area, 2,390 x 720 x 400 mm
Access ladder mounted on the right (in driving direction)
Lifting axle on the front axle with TEBS E control, depending on the current axle load and current loading status
Load gauge for determining axle loads, including load chart
HRM metallization of the outer frame: Complete steel construction blasted, then defined visible areas metallized with ZINACOR 850 hot finish
Küçük ilan
Overpelt
2.688 km
Düşük yükleyici
FAYMONVILLEMAX Trailer 2-AXES LOWLOADER 21T - ALU RAMPS - ...
Ara
Durum: mükemmel (kullanılmış), dingil konfigürasyonu: 2 dingil, izin verilen dingil yükü (dingil 1): 10.500 kg, izin verilen dingil yükü (dingil 2): 10.500 kg, ilk tescil: 06/2017, toplam uzunluk: 7.000 mm, toplam genişlik: 2.500 mm, toplam yükseklik: 880 mm, süspansiyon: hava, lastik boyutu: 235/70 R17.5, lastik durumu: 75 yüzde, renk: diğer, Üretim yılı: 2017, Donanım: ABS, = Diğer seçenekler ve donanımlar =
- 2 aks
- Havalı süspansiyon
= Diğer bilgiler =
Aks konfigürasyonu
Lastik ebatları: 235/70 R17.5
Lastik diş derinliği: %75
Frenler: kampana frenler
Arka aks 1: çift teker; Maks. aks yükü: 10.500 kg
Dusdpey D Hl Iofx Afveu
Arka aks 2: çift teker; Maks. aks yükü: 10.500 kg
Ağırlıklar
Azami toplam ağırlık: 21.000 kg
Durum
Teknik durumu: çok iyi
Görsel durumu: çok iyi
Hasar: yok
Kimlik
Plaka: QALO590
Küçük ilan
Essen
2.594 km
Alçak şasi dorse
FAYMONVILLEMultimax Satteltieflader (1+2) - nachlaufgelenkt
Ara
Durum: yeni, azami yük ağırlığı: 36.410 kg, toplam ağırlık: 48.000 kg, dingil konfigürasyonu: 3 dingil, toplam genişlik: 2.540 mm, Donanım: ABS, You can find our entire stock of vehicles, including those available for immediate or short-term delivery, on our website.
Partial list of features. Full specification available on request.
NECK:
* SNT-design gooseneck for optimized loading platform length, approx. 3,700 mm long, with rear taper approx. 1,000 mm x 10°
* For tractor units: 4 x 2, 6 x 2, and 6 x 4
* Plug-in steel front bulkhead, approx. 400 mm high
* ASPÖCK-UNIBOX
* 3 kW electro-hydraulic power unit for hydraulic operations (excluding hydraulic winches)
* Approx. 40 mm hardwood decking above gooseneck
Dsdpfx Afoy Auh Iovouu
* 2-inch kingpin
* Gooseneck guide plate for fifth wheel, approx. 500 mm wide
* Rear of gooseneck equipped for ALU approach ramps
* Round NATO socket on front connection strip (Maeler & Kaege VG 96 917)
* 4 wheel chocks with holders ahead of the front bulkhead
* 1 pair of stake pockets embedded in the gooseneck, for plug-in stakes approx. 100 x 50 mm (inside the chassis beam)
EQUIPMENT:
* Loading platform approx. 8,800 mm long, extendable version approx. 4,100 mm, rear with taper approx. 500 mm x 10°
* Recess in the loading area and into the taper for excavator dipper stick accommodation, approx. 2,490 x 750 x 210/290 mm (L x W x H)
* Pneumatic locking with conical locking pin and reinforced locking positions; supply lines are routed protected inside the extendable beams and automatically adjust to the platform length
* TPMS tire pressure monitoring system per ECE R 141
* BPW axles and suspension, 1st and 2nd axle fixed, 3rd axle steered trailing
* 3rd axle with electro-magnetic reverse lock, can be activated by reverse gear and manually
* Technical axle load: 12,000 kg per axle, air suspension with lift and lowering valve
* 235/75 R 17.5 3PMSF twin tires. Brand of our choice
* Mechanical landing legs with 2-speed gearbox and crank. JOST Modul B – static test load approx. 50,000 kg
* Hardwood floor (approx. 50 mm thick) throughout the load area and interrupted between axles (increases coefficient of friction)
* 1 intermediate table, approx. 300 mm wide, for the large cross-section extension tube. Intermediate table with recessed platform and extendable mountings for aluminium bridging elements
* Platform locking with conically welded locking profiles every approx. 250 mm. Includes pre-tensioning plate
* 1 pair of lashing rings on the front cross member (LC 10,000 daN)
* 9 pairs of recessed lashing rings in the outer frame of the platform, foldable outwards (LC 10,000 daN)
* 1 pair of fixed wheel recesses ahead of the axles, open up to the gooseneck cross member, approx. 700 x 410 mm (W x D)
* Wheel recesses with square climbing strips approx. 15 x 15 mm, with widenings at the bottom (if vehicle equipped with extendable outriggers)
* 1 pair of fixed wheel recesses, approx. 1,480 x 700 x 410 mm (L x W x D), in the load area between the 1st and 2nd axle
* Wheel recesses with square climbing strips approx. 15 x 15 mm and bottom widenings
* Aluminium covers for wheel recesses ahead of the axles and between the 1st and 2nd axle, which can also serve as extension planks (if vehicle equipped with extendable outriggers)
* Lockable aluminium elements fitted onto the extension pipes of the outriggers
* 1 pair of mechanical rear supports
* 1st axle with traction aid
* Painted sand...
Güven mührü
TruckScout24 tarafından sertifikalandırılmış bayiler

Küçük ilan
Essen
2.594 km
Alçak şasi dorse
FAYMONVILLEMAX Trailer MAX100 Semi-Tieflader Planenaufbau
Ara
Durum: yeni, azami yük ağırlığı: 40.320 kg, toplam ağırlık: 50.960 kg, dingil konfigürasyonu: 3 aks, toplam genişlik: 2.540 mm, Donanım: ABS, You can find our complete stock of vehicles, including those available immediately and at short notice, on our website.
Equipment excerpt. Full equipment details available upon request.
Gooseneck:
* Gooseneck with rear chamfer of approx. 750 mm x 10°. 3 pairs of lashing rings (LC 5,000 daN)
* Hardwood flooring, approx. 30 mm thick. Loading area with 5 pairs of folding lashing rings to the outside (LC 5,000 daN)
* 3 pairs of folding lashing rings to the outside (LC 10,000 daN)
* 1 pair of flat lashing rings at the front of the loading area (LC 10,000 daN)
Djdpfx Afsy Aug Djvsuu
* Hardwood flooring, approx. 48 mm thick, with checker plate surface above the axles
Landing legs:
JOST mechanical landing legs with 2-speed gearbox, lift capacity approx. 24 t (test load approx. 50 t)
Tyres:
* Tyres 205/65 R17.5 - brand of our choice
TPMS:
* TPMS tyre pressure monitoring system pursuant to ECE R 141
Axles:
* BPW axles, two rigid axles, two steering axles
* Air suspension with lifting/lowering feature
* Drum brakes
* Self-tracking steering axles with electro-magnetic reverse lock, activated via reverse gear or manually
Brake system:
* WABCO braking system according to EU regulations with EBS-E (4S3M)
Electrical system:
* Electrical system according to EU standards, 24 volt LED lighting by ASPÖCK-NORDIK (ASS3)
* All LED side marker lamps flash synchronously with the indicator
* ASPÖCK-UNIBOX at the front connection strip with 24N, 24S & 15-pin sockets according to ISO. 24N ISO-1185 24S ISO-3731, 15-pin ISO-12098
Steel construction:
* Steel construction made of high-strength fine-grained steels
* Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)
Paintwork:
* HRM metallization of the complete vehicle chassis with ZINACOR 850 (85% zinc/15% aluminium) for optimum corrosion protection
* Trailer color RAL 3002 Carmine Red
* Wheels Silver Grey
* Tarpaulin RAL 9006 (brilliant direct)
Options included:
* One mounting bracket each for warning signs on the left and right at the gooseneck and rear, including socket
* 2-inch king pin
* Galvanized steel bulkhead
* Yellow-red air couplings at the galvanized front connection strip
* 4 wheel chocks with holder mounted on the bulkhead
* 3-level wooden boards
* Galvanized folding supports under the loading area chamfer
* Mount for beacon at the rear of the trailer
* Height-adjustable tarpaulin structure – approx. 3,960 mm
* Galvanized front bulkhead with a tensioning mechanism for the sliding curtains. Height-adjustable by approx. 400 mm
* EDSCHA roof, forward-slidable on ALU roof bearer profiles (bolted to front and rear wall)
* 3 pairs of sliding stanchions in the loading area
* The body can be hydraulically widened at the rear to the left and right by approx. 750 mm
* Sliding roof with fold-up portal beam
* Sliding tarpaulin with 700 mm surplus in length, with tension straps approx. every 600 mm. Height to top edge of body approx. 3,960 mm (loaded)
* Driving with the sliding roof open is not permitted and will cause damage to the tarpaulin
* Rear of the body with closed anodized ALU swing doors
* Hook-in rail for ALU drive-on ramps at the rear of the vehicle
* Control valves for hydraulic body widening mounted on the right trailer side
* White reflective tape in accordance with EU regulations, red tape at the rear
* Electro-hydraulic unit mounted at rear under loading area
* Mud flaps at the rear of the trailer
* European reflective warning signs (red-yellow) at the rear of the tr
Küçük ilan
Essen
2.594 km
Alçak şasi dorse
FAYMONVILLEMAX110 Semi-Tieflader
Ara
Durum: yeni, azami yük ağırlığı: 36.590 kg, toplam ağırlık: 48.000 kg, dingil konfigürasyonu: 3 dingil, toplam genişlik: 2.540 mm, Donanım: ABS, You can find our complete vehicle inventory, including immediately and soon-available vehicles, on our website.
Excerpt from the equipment list. Full equipment details available on request.
Gooseneck:
* Gooseneck with front chamfered corners approx. 45°, and with rear bevel approx. 750 mm x 10°. 3 pairs of lashing rings (LC 5,000 daN)
* Hardwood flooring approx. 30 mm thick
Loading Area:
* Extendable loading area with rear bevel approx. 1,000 mm x 8°
* 5 pairs of fold-out lashing rings (LC 5,000 daN)
* 3 pairs of fold-out lashing rings (LC 10,000 daN)
* 1 pair of recessed lashing rings in the front of the loading floor (LC 10,000 daN)
* Cut-outs in the outer frame for attaching tension straps (LC 2,000 daN)
* Hardwood flooring approx. 48 mm thick, over the axles with tread plate covering
Tyres:
Duedpfxjy Auifo Afvju
* Tyres 245/70 R 17.5 3PMSF – brand of our choice. Load index (146/146F)
TPMS:
* TPMS tire pressure monitoring system according to ECE R 141. Data transfer to the truck is via the standardized EBS interface ISO 11992. For correct display, the truck must be able to receive and show this data.
Landing Legs:
* JOST landing legs (mechanical) with 2-speed gearbox for approx. 24 t lift capacity (approx. 50 t test load)
Axles:
* BPW axles and suspension, all axles hydro-mechanically forced-steered
* Technical axle load: 12,000 kg each
* Air suspension with lift and lower valve
* Axle tools
Brake System:
* WABCO braking system in accordance with EU regulations with EBS-E (2S2M), without connecting lines to the tractor unit
Steel Construction:
* Steel construction made of high-strength fine-grained steels. Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)
Electrical System:
* Electrical system according to EU regulations, lighting 24 Volt ASPÖCK-NORDIK (ASS3), ASPÖCK-UNIBOX at the front terminal strip with sockets 24N, 24S & 15-pin connection according to ISO. 24N ISO-1185, 24S ISO-3731, 15-pin ISO-12098
Paintwork:
* Complete steel structure is automatically blast-cleaned after welding using a shot blasting machine
* Second abrasive blasting with corundum for optimal adhesion of the coating system
* Final painting with 2 coats of 2-component topcoat, single colour in RAL 3002 Carmine Red, according to RAL System 841GL
* Rims in silver-grey
* Rear section metalized and painted in RAL 9010 (pure white)
Accessories:
* 2-inch king pin
* One galvanized steel front wall, approx. 400 mm high
* Yellow-red air couplings on the galvanized front connection strip
* Spare wheel holder in front of the front wall (without spare wheel)
* Electro-hydraulic power pack
* Remote steering front and rear via cable remote control with push buttons, with single-track axle control (without installation in the tractor unit)
* Attachment bar for ALU loading ramps on gooseneck with integrated impact protection
* At the gooseneck and rear panel, left and right, each with a holder for warning signs including socket
* Holder for a beacon at the rear of the trailer
* Galvanized foldable supports under the rear bevel of the loading area
* 1 pair of recessed lashing rings along the centre beam at the rear in the inclined section (LC 10,000 daN)
* Axle load gauge with load diagram
* On the tread plates on the gooseneck and loading area, a painted sand layer for slip protection
* On the gooseneck, removable aluminium side and rear boards, approx. 2,440 x 400 mm (L x H). The rear galvanized...
Küçük ilan
Essen
2.594 km
Alçak şasi dorse
FAYMONVILLEMAX Trailer MAX100 Semi-Tieflader 2tlg. Rampen
Ara
Durum: yeni, azami yük ağırlığı: 58.860 kg, toplam ağırlık: 73.000 kg, dingil konfigürasyonu: 3 aks, toplam genişlik: 2.540 mm, Donanım: ABS, Our complete inventory of vehicles, including units available for immediate or short-term delivery, can be found on our website.
Excerpt from the equipment list. Full specifications available on request.
Gooseneck:
* Gooseneck with beveled front corners approx. 45°, rear bevel approx. 750 mm x 10°
* 3 pairs of lashing rings (LC 5,000 daN). Hardwood flooring approx. 30 mm thick
Extendable loading platform:
* Loading platform in extendable design with rear bevel approx. 500 mm x 8°
* 8 pairs of foldable lashing rings (LC 10,000 daN)
* 1 pair of flush-mounted lashing rings at the front of the loading platform (LC 10,000 daN)
* Cutouts in the outer frame of the platform for securing straps (LC 2,000 daN)
* Hardwood flooring approx. 48 mm thick, over the axles with checker plate covering
Two-section steel ramps:
* One pair of galvanized two-section steel ramps, approx. 2,750 + 1,400 x 900 mm, with Super Grip rubber covering
* Ramp with hydraulically folding ramp sections
* Hydraulic lifting unit, hydraulically adjustable
* Maximum load per pair: 50,000 kg
* In accordance with Regulation 1230/2012/EU, ramps with a length less than 300 mm do not have to be included in the overall vehicle length of 16,500 mm when in driving position
Axles:
* BPW axles and suspension, 1st axle steered (leading), 2nd and 3rd axles fixed, 4th and 5th axles trailing steer, air suspension with lift/lower function, drum brakes
* Trailing steering axles with electro-magnetic reverse lock, activated automatically when reversing or manually
* Technical axle load: 12,000 kg each
Tyres:
Dsdpfoy Augwex Afvouu
* Tyres 235/75 R 17.5 3PMSF – make at our discretion
TPMS:
* Tyre Pressure Monitoring System (TPMS) compliant with ECE R 141. Data transfer to the truck unit is via the standardized EBS interface in accordance with ISO 11992. For correct display, the truck unit must be able to receive and display this data.
Landing legs:
* JOST mechanical landing legs with two-speed gearbox for approx. 24 t lifting capacity (approx. 50 t test load)
Brake system:
* Wabco braking system in accordance with EU regulations with EBS-E (4S3M), without connector lines to the tractor unit
Steel construction:
* Steel structure made from high-strength fine-grained steels
* Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)
Electrical system:
* Electrical system according to EU regulations, lighting 24 Volt ASPÖCK-NORDIK (ASS3)
* All LED side marker lights flash with the indicators
* ASPÖCK-UNIBOX at the front connection panel with sockets 24N, 24S & 15-pin connectors as per ISO. 24N ISO-1185, 24S ISO-3731, 15-pin ISO-12098
Paintwork:
* Complete steel construction automatically shot blasted after welding using a wheel blast system
* Second blasting using corundum for optimal adhesion of paint system
* HRM metallization of the entire vehicle chassis with ZINACOR 850 (85% zinc / 15% aluminum) to ensure maximum corrosion protection
* Final coating using 2 layers of 2K topcoat, single-color in RAL 3002 carmine red, as per RAL system 841GL
* Rear section metallized and painted in RAL 9010 pure white
Including the following additional equipment:
* 2-inch king pin
* One galvanized steel front wall approx. 400 mm high
* One spare wheel holder in front of the front wall
* Yellow-red air couplings at the galvanized front connector panel
* A bracket for a rotating beacon at the rear of the trailer
* Galvanized supports under the platform’s rear bevel
* Super Grip rubber ma
Küçük ilan
Essen
2.594 km
Alçak şasi dorse
FAYMONVILLEMAX Trailer MAX100 Semi-Tieflader Planenaufbau
Ara
Durum: yeni, azami yük ağırlığı: 36.020 kg, toplam ağırlık: 48.000 kg, dingil konfigürasyonu: 3 dingil, toplam genişlik: 2.540 mm, Donanım: ABS, You can find our complete range of vehicles, including immediately and soon-to-be available models, on our website.
Excerpt from the equipment. Full specification available upon request.
Gooseneck:
* Gooseneck with rear bevel, approx. 750 mm x 10°
* 3 pairs of lashing rings (LC 5,000 daN)
* Hardwood flooring, approx. 30 mm thick
Load area:
* Load area with rear bevel, approx. 1,000 mm x 8°
* 5 pairs of fold-out lashing rings (LC 5,000 daN)
* 3 pairs of fold-out lashing rings (LC 10,000 daN)
* 1 pair of horizontal lashing rings at the front of the load area (LC 10,000 daN)
* Hardwood flooring, approx. 48 mm thick; over the axles, chequer plate covering
Two-part steel ramps:
* 1 pair of galvanized, two-part steel ramps, approx. 3,185 + 1,420 x 1,250 mm, with grating (C40/5). Point load approx. 2.8 t on a 20 x 20 cm area
* Ramps with hydraulically foldable sections and hydraulic lifting device
* Maximum load per pair: 30,000 kg
Landing legs:
* JOST landing legs (mechanical) with 2-speed gearbox for approx. 24 t lifting capacity (approx. 50 t test load)
Axles:
* BPW axles and suspension, 2 fixed axles, 1 trailing steer axle
* Technical axle load: 12,000 kg each
* Electromagnetic reverse lock, activated via reverse gear and manually
* Air suspension with lift and lower valve
Tyres:
* Tyres: 235/75 R 17.5 3PMSF – make at our discretion
TPMS:
* Tyre Pressure Monitoring System (TPMS) according to ECE R 141
Braking system:
Dodpfxsy Auhus Afvjuu
* WABCO braking system compliant with EU regulations, with EBS-E (2S2M), without connection lines to the tractor unit
Steel construction:
* High-strength fine-grained steel construction
* Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)
Electrical system:
* Electrical system in accordance with EU regulations, LED lighting 24 Volt ASPÖCK-NORDIK (ASS3)
* All LED side marker lights flash with the indicator
* ASPÖCK-UNIBOX at the front connection rail with 24N, 24S & 15-pin sockets according to ISO: 24N ISO-1185, 24S ISO-3731, 15-pin ISO-12098
Coating:
* HRM metallization of the entire chassis using ZINACOR 850 (85% zinc / 15% aluminium) for optimal corrosion protection
* Final coating with 2 layers of 2-component topcoat, single-colour, RAL 3002 carmine red, according to RAL System 841GL
* Rear section metallized and painted in RAL 9010 (pure white)
* Wheel rims in silver
Incl. accessories:
* One bracket each for warning signs (left/right) at gooseneck and rear, incl. socket
* 1 spare wheel carrier under the load area on the right
* 2-inch kingpin
* One galvanized steel front wall
* At the galvanized front connection rail: yellow-red air couplings
* 4 wheel chocks with holders at the front wall
* 3-tier wooden planks
* Galvanized folding supports under the rear bevel
* Holder for beacon at the rear of the trailer
* Height-adjustable curtain structure – approx. 3,960 mm
* Galvanized front wall with locking mechanism for sliding curtains, height adjustable by approx. 400 mm
* EDSCHA brand roof, forward-slidable on aluminium roof profile (bolted to front and rear walls)
* 3 pairs of movable stanchions in the load area
* Body hydraulically expandable to left/right at rear by approx. 750 mm
* Sliding roof with high-lift portal carrier
* Sliding curtain with approx. 700 mm extra length, tensioning straps spaced approx. 600 mm apart. Height O
Sizin için aramayı kolaylaştırıyoruz: "faymonville stz yarı römorklar"
Yeni teklifleri hemen ve ücretsiz olarak e-posta ile alırsınız.
Arama görevini istediğiniz zaman kolayca sonlandırabilirsiniz.
Kullanılmış Faymonville Stz Yarı Römorklar (184)
Şimdi 120.000’dan fazla ikinci el araçla TruckScout24 genelinde arama yapın.En popüler kategorileri inceleyin:
- Ackermann-Fruehauf Vts Yarı Römorklar
- Faymonville Alçak Yükleyici
- Faymonville Diğer
- Faymonville Fragmanlar
- Faymonville Ilo Yarı Römorklar
- Faymonville Platform
- Faymonville Platform Açık
- Faymonville Prefamax
- Faymonville Standart Yapı
